Vega Vayu 4G GSM – IoT Temperature Monitoring Data Logger System

• Advanced Hardware Specifications: The device features a compact, ruggedized form factor measuring 100 x 66 x 29mm and weighing only 165g. With an IP64 rating, the Vega Vayu 4G GSM Temperature and Humidity Data Logger is protected against dust and water splashes, making it ideal for harsh transit environments.

• Vega Vayu 4G GSM Cloud Platform: Users gain access to a centralized, real-time dashboard featuring GIS tracking, automated PDF/Excel reporting, and instant SMS/Email/WhatsApp alerts. This cloud integration allows for 24/7 remote monitoring of the Vega Vayu 4G GSM Temperature and Humidity Data Logger from any global location.

• Global Communication Capabilities: Equipped with multi-network support (LTE CAT1, GSM), the Vega Vayu 4G GSM Temperature and Humidity Data Logger maintains seamless connectivity across 4G and 2G bands, ensuring consistent data transmission even during international transit.

• Multi-Parameter Sensor Suite: Beyond thermal monitoring, the Vega Vayu 4G GSM Temperature and Humidity Data Logger tracks humidity, ambient light (to detect unauthorized box openings), vibration (for physical shock monitoring), and door events.

• Superior Data Integrity: Featuring "store-and-forward" technology, the Vega Vayu 4G GSM Temperature and Humidity Data Logger can cache up to 17,000 readings locally if a network signal is lost, automatically uploading the data once connectivity is restored to prevent any gaps in the audit trail.

Elaborate Product Offerings of Vega Vayu 4G GSM Temperature and Humidity Data Logger

Specialized Capabilities of Vega Vayu 4G GSM Temperature and Humidity Data Logger

• The technical prowess of the Vega Vayu 4G GSM Temperature and Humidity Data Logger lies in its metrological precision.

• The internal sensors provide a measurement accuracy of ±0.5°C for temperature and ±3%RH for humidity across a standard operating range of -30°C to 60°C. For specialized ultra-low temperature applications, such as dry ice shipments or -80°C cryogenic freezers, the Vega Vayu 4G GSM Temperature and Humidity Data Logger offers extended range probes to ensure high-fidelity monitoring in extreme environments.

• To ensure complete traceability, the device utilizes triple-mode positioning technology, combining GPS, LBS (Location Based Services), and WiFi triangulation.

• This allows the Vega Vayu 4G GSM Temperature and Humidity Data Logger to provide accurate location data even when inside metal containers or deep within warehouses.

• Powering these features is a high-capacity 4000mAh rechargeable battery, which supports up to 60 days of continuous operation at a 1-hour reporting interval.

• Additionally, the Vega Vayu 4G GSM Temperature and Humidity Data Logger is purpose-built for regulatory rigor, meeting all requirements for FDA 21 CFR Part 11 and WHO-GDP standards, ensuring that electronic records are trustworthy and reliable.

• The system enables trajectory analysis, allowing users to track shipment routes and understand environmental conditions throughout the logistics journey.

• Instant real-time alarms and notifications are generated whenever predefined thresholds are exceeded, enabling immediate corrective actions to protect valuable assets.

Technical Specifications

Get in touch

Share with visitors how they can contact you and encourage them to ask any questions they may have.

Phone

+91-76-96-39-63-93

Email

support@vegadataloggers.com

FCC

EN 12830

US FDA 21 CRF PART 11

WHO-GMP

RoHS

CE

Regulatory Compliance & Certifications

ISO/IEC 17025:2017 NABL Accredited Calibration Laboratory

Vega operates a NABL-accredited calibration laboratory and holds a valid certification in accordance with ISO/IEC 17025:2017, demonstrating our commitment to maintaining the highest standards in calibration and testing. This accreditation confirms our technical competence, ensuring that all calibration processes are performed with precision, reliability, and adherence to internationally recognized standards.

Key Benefits

• Ensures metrological traceability and high measurement accuracy.

• Demonstrates the technical competence and reliability of our calibration processes.

• Provides international recognition and credibility for calibration and test results.

• Supports regulatory compliance and quality assurance in pharmaceutical, healthcare, food, and other regulated industries.

User-Friendly Dashboards for Complete Operational Visibility

Advanced Reporting & Audit Trails

• Dynamic Visualizations: Export comprehensive environmental data seamlessly in both detailed tabular data formats and intuitive graphical charts.

• Granular Audit Trails: Generate strict, compliance-ready logs tracking all portal activities specifically by individual user and by distinct device.

• Audit Readiness: Maintain immutable historical records to effortlessly satisfy WHO-GDP, FDA 21 CFR Part 11, and internal quality assurance requirements.

Comprehensive Alert Management System

• Multi-Channel Notifications: Receive instant excursion warnings through direct SMS, automated voice calls, and local sound or light indicators.

• Mandatory Acknowledgement: Enforce accountability by requiring assigned personnel to formally acknowledge triggered alerts within the portal.

• Multi-Level Mapping: Organize devices seamlessly across global locations, operational hubs, and specific facility areas for streamlined visibility.

Asset Tracking & Organizational Hierarchy

• Lifecycle Tracking: Monitor real-time asset positioning and current hardware operational status continuously.

• Calibration Renewals: Automate critical maintenance schedules with proactive reminders, ensuring your loggers remain fully compliant and never miss a mandatory calibration cycle.

Advanced Reporting & Audit Trails

• Dynamic Visualizations: Export comprehensive environmental data seamlessly in both detailed tabular data formats and intuitive graphical charts.

• Granular Audit Trails: Generate strict, compliance-ready logs tracking all portal activities specifically by individual user and by distinct device.

• Audit Readiness: Maintain immutable historical records to effortlessly satisfy WHO-GDP, FDA 21 CFR Part 11, and internal quality assurance requirements.

Consignment & Shipment Management

• Shipment Creation: Quickly generate and configure new consignments, seamlessly assigning specific temperature loggers to individual transport vehicles or packages.

• End-to-End Visibility: Monitor the real-time journey of your active shipments from the origin warehouse directly to the final delivery destination.

• Transit Analytics: Evaluate transit times and overall cold chain integrity to confidently optimize future logistics and supply chain operations.

Industry Segments Using Vega Vayu 4G GSM Temperature and Humidity Data Logger

Third-Party Logistics (3PL) and Multi-Modal Cold Chain Providers

Logistics providers in transport epicenters like Bhiwandi, Navi Mumbai, and Panvel manage diverse client inventories that require constant environmental and security vigilance across complex routes involving trucks, trains, and planes. The Vayu IoT monitoring system is the essential tool these providers use to offer "Environmentally Guaranteed and Secure Logistics" as a premium service. These systems allow warehouse operators and fleet managers in Jeddah, Damam, and Riyadh to verify the thermal status of cargo at every handover point via a live cloud dashboard.

Biotechnology Research and Clinical Trial Management Facilities

The biotechnology sector in Bangalore, Jaipur, and Goa handles invaluable biological samples and experimental drugs that require strictly controlled, transcontinental transport for clinical trials. In this segment, the Vayu IoT system is a critical scientific instrument for documenting "Stability-in-Transit" and "Stability-in-Storage." Research labs use these devices to monitor clinical trial materials, where even a minor deviation during air or land transit can compromise years of research or the integrity of a trial.

Global Pharmaceutical and Biotechnology Manufacturing Clusters

In the high-output pharmaceutical hubs of Ahmedabad, Hyderabad, and Baddi, the Vayu IoT temperature monitoring system is the primary line of defense for life-saving medicinal products. This segment involves the manufacturing of vaccines, biological reagents, and high-value APIs that are extremely sensitive to even minor thermal fluctuations; a cooling failure in a stability chamber or a cold room in Chandigarh can result in the loss of an entire batch worth millions of dollars.

Advanced Electronics and Semiconductor Fabrication Corridors

The high-tech manufacturing belts of Noida, Bangalore, and Manesar utilize the Vayu IoT system to protect ESD-sensitive components, silicon wafers, and high-precision medical machinery during the fabrication process. In semiconductor logistics and production, temperature fluctuations can introduce physical stress on delicate micro-circuitry, leading to long-term reliability failures and significant yield loss. Our monitoring systems provide the high-frequency thermal data and real-time alerts.

Industrial Use Cases of Vega Vayu 4G GSM Temperature and Humidity Data Logger

Compliance Management for Multi-State Regional Logistics and Security

Large pharmaceutical and electronics companies with distribution centers in Lucknow, Jaipur, and Kolkata face the challenge of maintaining consistent environmental logs for thousands of monthly vehicle transits across diverse climatic zones. By implementing a standardized use of Vayu systems, the corporate Quality Manager in Mumbai can oversee the status and location of every regional shipment from a single dashboard. The system automatically flags any vehicle that has experienced a temperature excursion.

Proof of Quality for Specialized Art and Museum Courier Transit

Irreplaceable cultural artifacts in cities like Jaipur and Kolkata require incredibly stable environments during regional and international transit. The Vayu system is used to provide continuous, live tracking of micro-climates and the precise geographic location within specialized shipping crates. Because these items are irreplaceable, the monitoring system acts as an objective, live witness to the environmental stability inside the vehicle or aircraft.

Real-Time Safeguarding of High-Value Vaccine Stocks in Regional Hubs

One of the most vital use cases involves the transport and storage of vaccines from distribution hubs in Delhi or Mumbai to international sites in Jeddah or Riyadh. Vaccines are extremely sensitive to temperature excursions outside the 2°C to 8°C range. By deploying Vayu, the quality team receives an immediate SMS alert the moment the temperature rises above 8°C. If a reefer unit fails at a port in Dubai or if a warehouse compressor fails during a long-haul desert crossing, Vayu’s GSM connectivity ensures the excursion is flagged instantly.

Validation and Real-Time Mapping of Large-Scale Pharmaceutical Warehouses

Before a new large-scale warehouse in Noida, Hyderabad, or Pune can be commissioned for GxP storage, it must undergo a rigorous "Thermal Performance Validation" study. Vayu systems are placed in "worst-case" positions—near the ceiling, at the center, and against the outer walls—to identify how the HVAC system performs under extreme ambient heat. Unlike traditional loggers where data is checked after the study, Vayu allows Quality Managers to view the mapping progress live on a cloud dashboard.

Compliance Requirements Met by Vega Vayu 4G GSM Temperature and Humidity Data Logger

• The VAYU is designed to support compliance with major international audit and regulatory standards.

• It aligns with FDA 21 CFR Part 11 requirements by providing secure, tamper-proof, and unalterable electronic data records.

• The system generates automated analysis reports and detailed statistical data, ensuring reliable documentation and easy regulatory verification.

• It ensures complete quality traceability, allowing organizations to track and verify environmental conditions throughout the monitoring process.

• The VEGA Cloud Platform produces robust and systematic digital records that support regulatory inspections and internal quality audits.

• The system supports compliance with Good Manufacturing Practices (GMP), ensuring proper monitoring and documentation in manufacturing environments.

• The platform provides time-stamped monitoring records, offering verifiable proof of environmental consistency during routine inspections and compliance checks.

• The device’s high measurement accuracy supports organizations following ISO/IEC 17025:2017 standards for testing and calibration laboratories.

Why Vega is Your Ideal Partner

• Partnering with Vega Calibration And Validation Services LLP ensures reliable, on-time support and advanced IoT monitoring solutions regardless of geographical location.

• The VAYU can be rapidly deployed across major industrial hubs in India, including Mumbai, Delhi, Bangalore, Hyderabad, Ahmedabad, and Kolkata.

• Vega also supports operations in key manufacturing and pharmaceutical regions such as Indore, Chandigarh, and Manesar, ensuring consistent monitoring and technical assistance.

• Dedicated operational teams provide continuous support across important logistics hubs including Pune, Noida, Jaipur, Panvel, and Navi Mumbai to maintain uninterrupted cold chain operations.

• Vega also supports southern and international markets, including Chennai, Kochi, Coimbatore, and deployments across Saudi Arabia, including Riyadh, Jeddah, and Dammam, ensuring global reliability and technical support.

Frequently Asked Questions

Q: How does the Vayu IoT logger send alerts if the local facility power fails?
A: Vayu is designed for industrial resilience. It operates on global 4G/GSM networks and has its own internal rechargeable battery. This means it is completely independent of your facility's local IT or power infrastructure. Even if you have a total outage in Mumbai or Dubai, the logger continues to monitor and send alerts via the cellular network.

Q: Is the "Greater Range Probe" version necessary for dry ice monitoring?

A :Yes, absolutely. Standard internal sensors are rated for -30°C. For dry ice shipments (approx. -78°C) or liquid nitrogen (-196°C), the external probe version is required. This allows the sensor to be buried in the coolant while the GSM unit stays outside to maintain signal connectivity.

Q: Can the Vayu system integrate with our existing ERP or LIMS software?
A: Yes. Vayu features a robust API framework. Your IT teams in Noida or Riyadh can pull live data, alarm status, and coordinates directly into your proprietary software, allowing for automated batch release and centralized quality management.

Q: Is the data on the cloud secure from unauthorized modification?

A: Yes. The Vayu cloud platform is 21 CFR Part 11 compliant. It uses high-level encryption and features a time-stamped system audit trail. Every user action, from alarm acknowledgment to setting changes, is recorded and cannot be deleted or altered.

Q: How often do these loggers need to be calibrated to stay compliant?

A: Typically, for GxP and ISO 17025 compliance, loggers should be calibrated annually. Vega provides on-site and laboratory calibration services across Ahmedabad, Hyderabad, and the GCC region to ensure your devices remain within their specified accuracy limits.
